Original and New Yaskawa Varispeed G7 Series CIMR-G7A25P5 In Stock
| Place of Origin | china |
|---|---|
| Brand Name | Yaskawa |
| Certification | CCC,CE |
| Model Number | CIMR-G7A25P5 |
| Minimum Order Quantity | 1 |
| Price | USD$970/PC |
| Packaging Details | Original |
| Delivery Time | 1 Weeks |
| Payment Terms | L/C, D/A, D/P, T/T, Western Union, MoneyGram |
| Supply Ability | 100 |
Contact me for free samples and coupons.
Whatsapp:0086 18588475571
Wechat: 0086 18588475571
Skype: sales10@aixton.com
If you have any concern, we provide 24-hour online help.
xProduct Details
| Product Type | INVERTER | Maximum Applicable Motor | 5.5KW |
|---|---|---|---|
| Voltage Class | Three-Phase 200 V | Output Capacity | 10 KVA |
| Rated Output Current | 27A | Weight | 12KG |
| Highlight | Original Yaskawa Varispeed G7 Series,New Yaskawa Varispeed G7 Series,Yaskawa Varispeed G7 Series CIMR-G7A25P5 |
||
Product Description
Yaskawa Varispeed G7 Series CIMR-G7A25P5
Features
Performance Features
Ratings: 0.5 to 150 HP, 240 VAC
0.5 to 500 HP, 480 VAC
Overload capacity: Heavy duty, 150% for 1 minute, 200% peak
Starting torque: 150% at frequency;
1.0Hz (V/f), 0.5Hz (open loop vector), 0.0Hz (closed loop vector)
Output frequency: 0.01 to 400 Hz
Output frequency resolution: 0.001 Hz
Speed control range:
40:1 (V/f), 200:1 (open loop vector), 1000:1 (closed loop vector)
Speed regulation:
1.0% (V/f), 0.2% (open loop vector),
0.01% (closed loop vector)
Speed response: 60 Hz
Torque response: 300 Hz
Speed reference resolution:
0.01 Hz with digital reference,
0.03 Hz with analog reference,
0.01 Hz with network reference
Speed/Torque/Position control
Zero-servo mode
Adjustable accel/decel: 0.01 to 6000 seconds
S-Curve: 0.00 to 2.50 seconds, adjustable for each corner
Stall prevention: Accel / decel / running
Power loss ride-thru: Auto-restart or inertia ride-thru
