IFM Dual Inductive Sensor For Valve Actuators IN0117 IND2004DAROA/SL/LS-500 RT

  • IFM Dual Inductive Sensor For Valve Actuators IN0117 IND2004DAROA/SL/LS-500 RT
  • IFM Dual Inductive Sensor For Valve Actuators IN0117 IND2004DAROA/SL/LS-500 RT
  • IFM Dual Inductive Sensor For Valve Actuators IN0117 IND2004DAROA/SL/LS-500 RT
  • IFM Dual Inductive Sensor For Valve Actuators IN0117 IND2004DAROA/SL/LS-500 RT
Place of Origin china
Brand Name IFM
Certification CE
Model Number IN0117
Minimum Order Quantity 1
Price USD$80
Packaging Details carton
Delivery Time 6-8weeks
Payment Terms L/C, D/A, D/P, T/T, Western Union, MoneyGram
Supply Ability 500pc

Contact me for free samples and coupons.

Whatsapp:0086 18588475571

Wechat: 0086 18588475571

Skype: sales10@aixton.com

If you have any concern, we provide 24-hour online help.

x
Product Details
Output Function 2 X Normally Open Sensing Range [mm] 4
Housing Rectangular Dimensions [mm] 40 X 26 X 26
Highlight

Dual Inductive Sensor For Valve Actuators

,

IN0117 Dual Inductive Sensor

,

LS-500 RT Dual Inductive Sensor
Leave a Message
Product Description
Product characteristics
Output function 2 x normally open
Sensing range [mm] 4
Housing rectangular
Dimensions [mm] 40 x 26 x 26
Electrical data
Frequency AC [Hz] 47...63
Operating voltage [V] 20...140 AC / 10...140 DC
Protection class I
Reverse polarity protection no
Outputs
Output function 2 x normally open
Max. voltage drop switching output DC [V] 5
Max. voltage drop switching output AC [V] 5
Minimum load current [mA] 5
Max. leakage current [mA] 0.8
Permanent current rating of switching output AC [mA] 200
Permanent current rating of switching output DC [mA] 200
Short-time current rating of switching output [mA] 900; (20 ms / 0,5 Hz)
Switching frequency AC [Hz] 25
Switching frequency DC [Hz] 25
Short-circuit proof no
Overload protection no
Monitoring range
Sensing range [mm] 4
Real sensing range Sr [mm] 4 ± 10 %
Operating distance [mm] 0...3.25
Accuracy / deviations
Correction factor steel: 1 / stainless steel: 0.7 / brass: 0.4 / aluminum: 0.3 / copper: 0.2
Hysteresis [% of Sr] 3...15
Switch-point drift [% of Sr] -10...10
Operating conditions
Ambient temperature [°C] -25...80
Protection IP 67
Tests / approvals
EMC
EN 60947-5-2
EN 55011 class B
MTTF [years] 502
Mechanical data
Weight [g] 78.5
Housing rectangular
Mounting non-flush mountable
Dimensions [mm] 40 x 26 x 26
Material stainless steel (1.4305 / 303); PBT
Displays / operating elements
Display
Switching status 2 x LED, red
Electrical connection
Required protection miniature fuse to IEC60127-2 sheet 1; ≤ 2 A; fast acting; Place the fuse outside the hazardous area.
Remarks
Remarks
Recommendation: check the unit for reliable function after a short circuit.
Pack quantity 1 pcs.
Electrical connection - plug
  Connector: 1 x 7/8"; coding: A
