WT2110B Film Coating Thickness Gauge With Colored Display

  • WT2110B Film Coating Thickness Gauge With Colored Display
  • WT2110B Film Coating Thickness Gauge With Colored Display
  • WT2110B Film Coating Thickness Gauge With Colored Display
  • WT2110B Film Coating Thickness Gauge With Colored Display
Place of Origin china
Brand Name Wintact
Certification CE
Model Number WT200A
Minimum Order Quantity 1
Price USD$50/PC
Packaging Details Plastic Box+Paper Carton
Delivery Time 5-8 work days
Payment Terms D/A, D/P, T/T, Western Union, MoneyGram
Supply Ability 1000

Contact me for free samples and coupons.

Whatsapp:0086 18588475571

Wechat: 0086 18588475571

Skype: sales10@aixton.com

If you have any concern, we provide 24-hour online help.

x
Product Details
Product Name Coating Thickness Gauge Power 2*1.5V AAA Batteries
Material ABS Color Blue
Highlight

Film Coating Thickness Gauge

,

Coating Thickness Gauge WT2110B

,

WT2110B Coating Thickness Gauge Colored Display
You can tick the products you need and communicate with us in the message board.
Measurement range 0~1.80mm/0~71.0mil
Car mode resolution:Car mode resolution 0.05mm/2mil
User mode resolution 0.01mm/1mil
Measurement error ±0.1mm
Minimum diameter of substrate 50mm
Minimum thickness of substrate 0.5mm
Temperature range 18~30℃
Work humidity range 10~80%RH
Leave a Message
Measurement range 0~1.80mm/0~71.0mil
Product Description

New Wintact Coating Thickness Gauge WT2110B Coating Film Thickness Gauge-colored Display Wintact WT200A WT100A







This product is a portable coating thickness gauge,which can quickly, nondestructively, and accurately measure non-metallic coating thickness (such as paint,film, etc.) of metal substrate. It Is widely used in detection areas like manufacturing industry, Car washing industry, metal processing industry, chemical industry,and commodity inspection.





Mini Coating Thickness Gauge possesses the following features:

1.Measure coating thickness of metal substrate
surface
2.Two modes: Car/User
3.Three measurement ways: single measurement,
continuous measurement, difference value
measurement
4.Three calibration functions: zero calibration,
two-point calibration, and basic calibration
5.Metric unit and imperial unit
6.Auto power off





Specifications


Measurement range
0~1.80mm/0~71.0mil
Car mode resolution
0.05mm/2mil
User mode esolution
0.01mm/1mil
Measurement error
±0.1mm
Minimum diameter of
substrate
50mm
Minimum thickness
of substrate
0.5mm
Temperature range
18~30℃
Work humidity range
10~80%RH
Power
2*1.5V AAA batteries







Accessories



Blister packaging*1
Host*1
Instructions*1
1.5V battery*2









WT2110B Film Coating Thickness Gauge With Colored Display 0WT2110B Film Coating Thickness Gauge With Colored Display 1WT2110B Film Coating Thickness Gauge With Colored Display 2WT2110B Film Coating Thickness Gauge With Colored Display 3
